10" LCD Display V2

10" LCD Display V2

10" LCD Display V2

The new 10" touch display with metal case is a robust multi-talent and suitable for a variety of applications. It is particularly characterized by its durable construction. The matt black metal case perfectly complements the hard coating of the display (H3).

The scope of delivery includes an adapter board with which you can attach all common single-board computers directly to the monitor.

Due to the additional USB connection you don't need a separate power supply for operation with the SBC. The display also works with conventional PC systems via the HDMI and VGA connection.

Small highlights are the BNC and AV connectors which can also be used to connect camera systems. Tinker in your workshop with your new Open Source project with the support of Raspberry and Co. and at the same time you have the possibility to solder with a camera microscope and to work with millimeter accuracy.

Specifications

Specifications

Display

10.1" (25.65cm)

Resolution

216,96x135.60mm

Contrast

800:1

Brightness

350 cd/m²

Connections

HDMI (1x), VGA (1x), AV (1x), BNC (1x), USB (2x)

Speaker

integrated

Power Supply

12V - 2000mA

Operating Temperature

0 - 50°C

Colors

16.7M

Special Features

Glare protection, hard coating (3H)

Dimensions

244 x 163 x 32mm

Weight

1.2 kg

Items Shipped

Display, adapter board for SBC, HDMI cable, USB cable (type A), USB cable (type A to micro-USB), power supply, 4x spare screws, 4x spacers, 4x nuts, remote control

EAN

4250236815633

Article No.

RB-LCD10-2
